The TSC MH241T and Honeywell PM45 differ in cost, durability, and features. Both models are designed for performance under tough conditions, but the TSC MH241T shines in several important areas, making it a better choice. This is a brief comparison of the 203 DPI models.
Cost
The TSC MH241T is significantly more affordable than the Honeywell PM45 and comes with a two-year warranty, compared to Honeywell’s one-year warranty.
This affordability, combined with lower replacement print head expenses and a longer warranty, makes the MH241T an attractive option for businesses looking to save on both upfront and long-term costs.
Display
The TSC MH241T has a 4.3-inch colour display with a straightforward interface, making it easy for users to manage printer settings and monitor status. In contrast, the Honeywell PM45 also offers a colour screen with sixteen buttons, which might complicate navigation for some users.
The TSC MH241T’s simpler display design provides a more user-friendly experience, especially for those prioritising ease of use.
Ribbon and Media Capacity
The MH241T holds a 600-metre ribbon, while the PM45 can only accommodate a 450-metre ribbon. This means fewer ribbon changes for the TSC, therefore reduced downtime and better efficiency in high-volume printing environments.
In terms of media capacity, the TSC MH241T and Honeywell PM45 are fairly comparable. The TSC MH241T can hold an 8-inch roll, whereas the Honeywell PM45 can handle rolls up to 8.38 inches in diameter.
The media thickness for the MH241T ranges from 2.36 mil (0.06mm) to 11 mil (0.28mm), while the PM45 ranges from 3 mils (0.08mm) to 10 mils (0.25mm), allowing the TSC to handle a wider range of media types, which can be useful for different printing needs.
The print width is another point of comparison. The TSC MH241T has a maximum print width of 4.09 inches, while the Honeywell PM45 can print up to 4.25 inches. This slight difference will be a plus for users needing a wider print area.
Resolution and Print Speed
Both the TSC MH241T and Honeywell PM45 offer identical resolution of 203 dpi and a maximum print speed of 14 inches per second. This means users can expect the same level of print quality and output speed from either printer, making them equally reliable in terms of resolution and performance.
Features
The TSC MH241T includes two USB host ports on the front, which can be used to connect peripherals like scanners or keyboards. It also supports media handling options, including cutters, peel-off kits, and an internal full-label rewind, available with MH241P, MH341P, and MH641P.
The “P” models (MH241P, MH341P, and MH641P) can be configured with a full 8″ internal rewind, while the standard models offer an optional 5″ internal rewind. This eliminates the need for an external rewinder, keeping labels neatly organised and ready for use.
In comparison, the Honeywell PM45 also offers versatile media handling but lacks the internal full-label rewind feature found in the MH241P and other TSC models.
While both printers provide USB ports for peripheral connections, the specific ease of access and placement on the TSC makes it a more convenient option for users.
Device Management
The TSC MH241T supports TSC Console and SOTI Connect for easy monitoring and control. SOTI Connect is an IoT device management solution that provides advanced capabilities for seamless integration and enhanced operational efficiency.
The Honeywell PM45 offers similar tools like PrintSet and SmartSystems.
Both provide web-based management, but the TSC MH241T’s broader software compatibility and SOTI support offer more flexibility and control.
Connectivity and Compatibility
The TSC MH241T offers RS-232, USB 2.0, Ethernet, USB host ports (front side), along with optional GPIO, a Bluetooth 4.2 and Wi-Fi combo module, and an optional factory-installed Bluetooth 5.0 module.
The Honeywell PM45 provides similar connectivity options, including Ethernet 10/100Base T, RS-232, USB 2.0, and USB Host, with optional Wi-Fi 802.11 a/b/g/n and Bluetooth 4.0.
Both printers support major printer languages. The TSC MH241T supports TSPL-EZD (compatible with EPL, ZPL, ZPL II, and DPL), while the Honeywell PM45 supports Fingerprint, IPL, DP, ZPL2, and DPL.
The TSC MH241T’s option for Bluetooth 5.0 provides improved wireless connectivity, making it a better fit for modern environments.
Operating Temperature and Humidity
The TSC MH241T is designed to perform reliably in a variety of industrial settings, with an operational temperature range from 0°C to 40°C and a humidity range of 25% to 85%. The Honeywell PM45 operates at temperatures starting from 5°C and has similar humidity requirements, making both printers suitable for most standard industrial environments.
Weight and Dimensions
The TSC MH241T weighs approximately 15.88 kg, while the Honeywell PM45 is lighter at 13.2 kg. The additional weight of the MH241T contributes to its sturdiness, which can be beneficial in more demanding industrial environments.
In terms of dimensions, the TSC MH241T measures 276 mm (W) x 326 mm (H) x 502 mm (D), whereas the Honeywell PM45 measures 284 mm (W) x 295 mm (H) x 483 mm (D).
Despite being slightly larger and heavier, the MH241T is built for tough industrial environments. Its extra weight adds stability and durability, making it a reliable choice for demanding operations where robustness really matters.
Conclusion
The TSC MH241T offers better value with superior durability, broader connectivity options, and a longer warranty—all at a lower cost compared to the Honeywell PM45.
For businesses seeking a reliable and efficient industrial printer, the MH241T is an ideal choice.
Ready to learn more? Download the full comparison PDF or Call PrimeTech at 1300 159 299 to find the right TSC printer for you!
